18
Raise Lift Off
Latches
Actuate To Release
Latches
Pinch Point
CAUTION
NP266 Rev C
Raise Lift Off
Latches
Actuate To Release
Latches
Pinch Point
CAUTION
NP266 Rev C
WARNING
Keep feet
clear of lift
while lowering
8"
Long Bumper
Short
Bumper
Padded section
of door bumper
faces out.
21"
(533mm)
Fig. 25
Fig. 26
Fig. 27
