11
To avoid personal injury and/or
property damage, permit only trained personnel to
operate jack. After reviewing these instructions,
get familiar with jack controls by running the jack
through a few cycles before loading vehicle on
jack.
Observe and avoid any pinch point areas of the
linkage mechanism.
1. Before loading a vehicle onto lift, ensure jack(s)
are fully lowered. Make sure the adapters are
in their most inbound and lowest position. Also
ensure rear jack is toward the center of the lift.
CAUTION
Move rear jack toward center of
runways of maximum vehicle clearance when
loading and unloading vehicles.
CAUTION
Always fully lower jack(s) to prevent
damage to the vehicle of lift.
2. After vehicle has been loaded, chock tires on the
opposite side in which the rolling jack is to be
used. If two rolling jacks are to be used, chock
the tires on the opposite side of the rolling jack to
be raised first.
Engage runway locks before rais-
ing vehicle on jacks! DO NOT operate lift while
jacks are engaged with a vehicle!
3. Place jack under vehicle at manufacturer’s
recommended pick-up points. Pull out the arms
to the proper pick-up points. Take up clearance
with rubber blocks.
Note: The rubber blocks can be stacked up 2 high.
SAFETY INSTRUCTIONS
• Never allow unauthorized or untrained persons to
operate rolling jack.
• Thoroughly train all employees in the use and care
of rolling jack.
OPERATING INSTRUCTIONS
• Never overload rolling jack. Capacity of rolling jack
is stated on the nameplate. Capacity should not be
exceeded.
• Observe and avoid any pinch point areas of the
linkage mechanism.
Do not stack rubber blocks more
than 2 high. Never set adapter blocks on edge.
Load evenly do not place weight on one side of the
jack.
CAUTION
Allow 12” minimum clearance
between vehicle and nearest overhead obstruction
before raising vehicle above runways. Failure
to comply could damage vehicle and/or cause
personal injury.
4. To Raise Rolling Jack: Connect the air supply.
Depress the pump lever and hold until the jack is
raised to the desired lock position. Lift the pump
lever to lower onto the locking latches.
5. To Lower Rolling Jack: Depress the pump lever to
raise rolling jack off of the locking latches. Lift and
hold latch release lever. Lift the pump lever until
the jack lowers completely.
CAUTION
Always fully lower jack to prevent
damage to the vehicle or lift.
Note: The Latch release handle is gravity return to
"reset" and the lowering valve handle is spring
return to "close" when released. Both must be held
open during the lowering cycle. DO NOT override
these "deadman" features.
4. Be sure the jack is fully lowered, the adapters are
in their lowest position, and bridge(s) are pushed
towards front of lift before driving the vehicle off
the lift.
