16
REF
TABLE 1 - JACK STRUCTURE
No. DESCRIPTION
VS043420011
Extension support
assembly
1
VS043420031
Long extraction
assembly
2
VS043430011 Fingerstrip 3
4
VS042301951
Pneumatic-hydraulic
pump support
5 VS043010060
Lower roll for external
connecting rod
6
VS043320300
Upper roll for internal
connecting rod
7
VS043415010
Internal connecting rod
assembly
8
VS237406 Shim
9
VS234187
10 VS903120
11 VS043415020
External connecting
rod assembly
12 VS043415210
13
VS243013
14
VS043415030
15 VS950020180
16
VS043410010
17
VS043415190
18
VS043415040
Upper pin for external
connecting rod
19
VS237411
20
VS043415050
Pin for nob
Hand grip
Pin
Seeger
Hook assembly
Spring
Frame assembly
Hook fulcrum pin
Washer
Pin
