Rotary X14 User Manual

17
REF
TABLE 2 - BRACKETS AND EQUIPMENT
No. DESCRIPTION
1
REF No. DESCRIPTION
2
3
4
5
VS04230160RG Spacer assembly
6
VS04230157RG Cap
7
VS043420070 Bearings support
8 VS042501810 Roller carrier
9 VS086460110 Pump retention washer
10 VS042501820 Roller
11 VS042501590 Spring pusher plate
12 VS950001100
Wheel free jack
support spring
13
VS042501830 Tie-rod
14
VS617010 Bearing ring
15 VS627007 Fifth wheel
16 VS042501800 Pin
17 VS043410020 Bracket assembly
18
VS043410080 Bracket assembly
19
20
VS043310460 Pin
21 VS043310391 Roller
22 VS237504 Washer
23
VS043410400 Holding brackets
24 VS243006 Snap ring
25
VS043410090 Bracket assembly
26
VS043420560 Small sliding block
27 VS043410040 Bracket assembly
28
VS043420250 Sliding block
29
VS043420470 Pin
30
VS043420480 Sliding block
31 VS043420490 Roller
32
VS950020230 Spring
33 VS043310440 Roller support
34
35 VS235035 Elastic pin
36 VS243005 Seeger
37 VS043380031 Stop hook assembly
38 VS043380051 Spacer
39 VS043410370 Bracket assembly
