TABLE 3 - OLEODYNAMIC SYSTEM
No. DESCRIPTION
1
VS043401010
Ø 80 cylinder
assembly
2
VSGU4560 Gaskets kit
3
VS305026 Fitting
4 VS304049 Fitting
5 VS317006 Rilsan Tube Ø6x4
6 VS305040 Fitting
7
VS043460090 Cylinder delivery pipe
8
VS304034 Fitting
9 VS043360081 Reduction
10
VS309533 Valve
11 VS312115 Fitting
