6
A10 Stereo Integrated Amplifier
About Rotel
Our story began over 50 years ago. Over the decades, we have received
hundreds of awards for our products and satised hundreds of thousands
of people who take their entertainment seriously – like you.
Rotel was founded by a family whose passionate interest in music led them
to manufacture high-delity components of uncompromising quality.
Through the years, that passion has remained undiminished and the family
goal of providing exceptional value for audiophiles and music lovers,
regardless of their budget, is shared by all Rotel employees.
Rotel’s engineers work as a close team, listening to, and ne tuning, each
new product until it reaches their exacting musical standards. They are
free to choose components from around the world in order to make that
product the best they can. You are likely to nd capacitors from the United
Kingdom and Germany, semiconductors from Japan or the United States,
while toroidal power transformers are manufactured in Rotel’s own factory.
We all have concerns about our environment. And, as more and more
electronics are produced it is especially important for a manufacturer to do all
it can to engineer products that have a minimum impact on the environment.
At Rotel, we are proud to do our part. We have reduced the lead content
in our products by using special lead-free ROHS solder and components.
Our engineers continually strive to improve power supply efciency without
compromise to quality. When in standby mode Rotel products use minimal
power to meet global Standby Power Consumption requirements.
The Rotel factory is also doing their part to help the environment through
constant improvements to product assembly methods for a cleaner and
greener manufacturing processes.
All of us at Rotel thank you for buying this product. We are sure it will bring
you many years of enjoyment.
Contents
Figure 1: Controls and Connections 3
Figure 2: Signal Input and Speaker Output Connection 4
Important Notes 5
About Rotel .......................................................6
Getting Started ....................................................7
A Few Precautions 7
Placement 7
Cables 7
AC Power and Control ...............................................7
AC Power Input
o
7
Power Switch
1
and Power Indicator
2
7
12 Volt Trigger Out
q
8
Input Signal Connections ..............................................8
Phono Input
e
and Ground Connection
w
8
Line Level Inputs
r
8
Recorder Connections
t
.............................................8
Preamp Outputs
y
.................................................8
Speaker Outputs
ui
..............................................8
Speaker Selector Switch
4
8
Speaker Selection 8
Speaker Wire Selection 8
Polarity and Phasing 8
Speaker Connection 8
Headphone Output
=
...............................................9
Media Player
3
...................................................9
Audio Controls .....................................................9
Volume Control
8
9
Balance Control
9
9
Tone On/Off Switch
7
9
Bass and Treble Controls
5
6
9
Function Control
-
9
Monitor Control
0
9
Protection Circuit ...................................................9
Troubleshooting ...................................................10
Power Indicator Is Not Illuminated 10
Fuse Replacement 10
No Sound 10
Specifications .....................................................10
