Rotex HPSU compact (V5) User Manual

8 x Technical data
61
BA ROTEX HPSU compact 2 - 04/2011
Heat technics
power data
Hot water volume without
re=heating at tapping rate
(8 l/min /12 l/min)
(TKW = 10 °C/TWW = 40 °C/TSP =
50 °C)
l/min 338 / 272 338 / 272
Hot water volume without
re=heating at tapping rate
(8 l/min /12 l/min)
(TKW = 10 °C/TWW = 40 °C/TSP =
60 °C)
l/min 527 / 468 527 / 468
Hot water volume without
re=heating at tapping rate
(8 l/min /12 l/min)
(TKW = 10 °C/TWW = 40 °C/TSP =
65 °C)
l/min 614 / 560 614 / 560
Reheating time (Wh) with a draw-off
quantity:
l/min
140l = 5820Wh (Øbathtub
draw-off quantity)
45 25
90 l = 3660 Wh (Ø shower draw-off
quantity)
30 17
Pipe connections
Cold and hot water inches 1" outer thread 1" outer thread
Heating feed and return flow inches 1" internal thread 1" internal thread
Refrigerant circuit
Number of circuits 1 1
Pipe connections
Number 2 2
Liquid line
Type inches Flanged connection Flanged connection
External diameter inches 1/4" outer thread 3/8" outer thread
Gas lines
Type Flanged connection Flanged connection
External diameter inches 5/8" outer thread 5/8" outer thread
Operating data
Operating range
Outdoor tempera-
ture range for
room heating/
cooling function
Heating
(min./max.)
°C -20 to 25 -25 to 35
Cooling
(min/max)
°C 10 to 43 10 to 46
Water heating
Heating
(min./max.)
°C 15 to 50 15 to 55
Noise level
(1
Audibility dBA 42 46
Acoustic pressure dBA 29 32
Unit
HPSU compact 508 HPSU compact 516
