3 Technical Description
3.1 General overview of screw compressor air ends
EVO2, EVO3, EVO3-G, EVO6, EVO6-G, EVO9, EVO9-G, EVO15, EVO15-G, EVO28,
EVO28-G, EVO42 and EVO42-G
Figure 3-1 Screw compressor air end EVO9
1. Air inlet
2. Air outlet (see installation drawing)
3. Cover plate
4. Drive shaft
5. Nameplate
6. Oil injection
7. Direction of rotation
8. Oil return line (non-return valve not integrated)
Note:
All EVO screw compressor air ends are of a similar design (except transmission versions).
