HOURLY SERVICE CHART EXEC 162F
REFERENCE SECTION 19: ROTOR HUB
PART NO. DESCRIPTION 25 50 100 200 250 500 1000 1500 2000
E49-6141 Rotor Hub Plate I R
E49-5100 Teeter Block Assembly I R
E49-5110 Teeter Block Bearing I R
E49-6281 Delrin Shim I
E49-6341 Stainless Steel Shim I
E00-2607 AN176-22A (3/8 x 2-1/4) Bolt I R
E49-6301 Main Rotor Drive Pin I R
E00-4802 Thin Washer I R
E49-5131 Snap Ring R
E49-6200 Thrust Blocks (M-S) I R
E49-6210 Thrust Washer I R
E49-1340 Thrust Blk. Align Bearing R
E49-1360 Thrust Block Liner I R
E49-1170 Rod End (Left Hand) I R
E49-1190 M/R Blade Pitch Link I R
E00-9300 Set Screws 1/4 x 1/4 I R
E00-9301 Set Screws 1/4 x 5/8 I R
E00-9305 Set Screws 1/4 x 3/16 I R
E49-6310 Pitch Pin (Outboard) R
E49-6320 Pitch Pin (Inboard) R
E00-2417 NAS-428-4-20 (1/4 x 2) Bolt, Full Thread I R
E00-2523 AN5-32A (5/16 x 3-1/4) Bolt I R
E49-7000 Main Shaft I R
E49-5140 Grease Fitting I R
E49-1331 Dust Cap I R
E49-3610 Non-Rotating Swash Plate I R
E49-3520 Swash Plate Bearing I R
E49-3541 Snap Ring, Non-Rotating Swash Plate I R
E49-3510 Rotating Swash Plate I R
E49-3230 Slider Ball Adjustment Collar I R
E49-4010 Cyclic Cable Mount I R
I INSPECT
R REPLACE
