Exec 162F Maintenance Manual

Rev. 1 10/01

HOURLY SERVICE CHART EXEC 162F

REFERENCE SECTION 19: ROTOR HUB CONTINUED

PART NO. DESCRIPTION 25 50 100 200 250 500 1000 1500 2000

E49-4100 Cyclic Mount Bearing I R

E49-4110 Snap Ring, Cyclic Mount I R

E49-3531 Snap Ring, Rotating Swash Plate I R

E49-3210 Collective Slider Ball I R

E49-3220 Spherical Bushing I R

E49-1530 Slider Ball Clamp I R

E49-1520 Slider Ball O-ring I R

E49-3240 Snap Ring Slider Ball I R

E00-9302 Set Screw (10-32) I R

E49-4610 Swash Plate Scissor I R

E49-4710 Scissor Clevis I R

E49-4720 Male Rod End 5/16 x 3/8 I R

E49-4810 Nylon Scissor Bushing I R

E49-4210 Collective Actuator Fork I R

E49-4310 Collective Scissor I R

E49-1380 Collective Scissor Mount I R

E14-6120 Control “T” I R

E14-1150 5/16 Male Rod End I R

E49-4510 Counter Balance I R

E15-1230 5/16 Male Rod End I R

E49-1410 Rod End Spacer I

E49-1470 Spring Bracket I

E49-1430 Tension Spring I R

E49-4800 Delrin Washer (Scissor) I R

E49-4830 Scissor Spacer 1-1/2" I R

E49-1180 Male Rod End 5/16" I R

E49-1510 Dust Boot I R

E49-1500 Rubber Shaft Protector I R

E49-1220 Main Thrust Bearing I R

E49-1230 Main Bearing Flange I R

E49-1260 Main Shaft Safety Spacer I R

E49-1251 Lower Main Shaft Bearing (Bearing Only) I R

E49-9100 Lower Main Shaft Bearing Weldment (Flange Only) I R

I INSPECT

R REPLACE

RotorWay Exec 162F - Page 88
