53
for more information about the “APP”s, contact your distributor or send an e-mail to:
wecare@roverinstruments.com
In OPTIC mode it is possible to analyze the spectrum and measure only vertical/low
band (VL) SAT transponders.
SAT spectrum SPAN “Full EXT”
(from 230 to 2610 MHz).
SAT spectrum SPAN “Full SAT”
(from 930 to 2250 MHz).
Touch “OPTIC” and then “SPECT”
or use the encoder.
After selecting the desired Operation Mode,
TV, CATV or SAT, press the “HOME” key.
