2-7
2.4 USING THE CONTROLS
The system is controlled by use of push buttons located on the front panel , a mouse,
and an optional keypad.
2.4.1 Front Panel Control Buttons
The front panel control buttons are located beneath the LCD display. Pressing a button
will initiate an action by the system. Details of the actions initiated by each button are
described below.
2.4.1.1 The “NDT” Button
Pressing the “NDT” button toggles the system between non-destruct and destruct testing
mode. The current mode is indicated as “NDT” or “DES” in the lower left corner of the
display.
2.4.1.2 The “PRINT REPORT” Button
Pressing the “PRINT REPORT” button sends report data to the printer port. If the printer
is not connected or has not been switched ON the display shows:
PRINTER NOT ON OR
NOT CONNECTED
Switch the printer on and/or check the connection, then press “PRINT REPORT” again.
The printout format can be modified in the TEST SETUP menu.
2.4.1.3 The “CLEAR DATA” Button
Pressing the “CLEAR DATA” button deletes ALL test data from system memory. The
system will prompt the operator for confirmation before deleting data.
2.4.1.4 The “MENU” Button
Pressing the “MENU” button toggles the display between the test screen and the main
menu screen. It also returns the display to the main menu from any sub-menu.
