RS PRO 264-1019 - Page 3

264-1019-IM-V02
3
264-1019
Sengs
Default Adjustment Range Pulse O/P
Adjust if
used
Comm
Modbus
System
Sengs
Oponal
1 Change Password 1000 NO / YES (0000 > 9998)
✓
2 Demand interval method Sliding Sliding / Fixed
✓
3 Demand interval duraon 15 1 > 30 min
✓
4 Demand interval length 1 1 > 30 min
✓
5 Pulse Output 2 Type VArh Total Wh / Total VArh / IMP Wh / EXP Wh /
IMP VArh / EXP VArh
✓
6 Pulse Weight 1000 1 / 10 / 100 / 1000 ( / Wh or VArh)
✓
7 Pulse Duraon 0.1 0.05 > 2.0 sec
✓
8 Slave ID 001 001 > 255 (Modbus)
✓
9 Baud rate Modbus: 9600 9600 / 19200 bps
✓
10 Parity Modbus: None None / Odd / Even
✓
11 Stop Bit 1 1 / 2
✓
12 Back Light O 0000 0 > 7200 Sec (0000 = never)
✓
13 Factory Default No No / Yes (does not reset Energy values)
✓
14 Reset Energy & Demand No
No / Yes (Password +1 i.e. 1001)
Only reset of Max Demand permied
✓
CONFIGURATION
Step A:
Enter Conguraon Menu
Step B: Buon operaons for Sengs adjustment:
Iniate ashing cursor
1
Change digit or opon, press to move cursor
2
HOLD 3 SEC to save Seng
3
Move to next Seng
4
HOLD 3 SEC to Enter Cong
(Same to Exit)
Password = 1000
(Refer to Step B for
buon operaons)
2
1
Ʃ Acve Energy kWh
x9 Apparent Power kVA
IP Acve Energy kWh x1 x10 Voltage V
x2 EP Acve Energy kWh x11 Current A
x3
Ʃ Reacve Energy kVArh
x12
Power Factor (PF)
x4 IP Reacve Energy kVArh x13 Frequency Hz
x5 EP Reacve Energy kVArh x14 MD Acve Power kW
x6
Ʃ Apparent Energy kVAh
x15
MD Reacve Power kVAr
x7 Acve Power kW x16 MD Apparent Power kVA
x8
Reacve Power kVAr
x17 >>
Ʃ
SUM (IP + EP)
EP
Export
IP
Import
MD
Max Demand
HOLD
10 Sec
COMM
TX/RX LOCK
ON < > OFF
COMM CONNECTION
Serial #
HOLD
10 Sec
Display Scroll
MANUAL < > AUTO
Idle 1min >>
x1
Integraon of Energy
Blinks at rate of
OPERATION
