10 11
Profeesional LCR Meter / English
Frequency = 1kHz
Frequency = 10kHz
Frequency = 100kHz
Range Resolution Cx Accuracy DF Accuracy Measurement Mode
2000.0pF 0.1pF 3.5%±15d 3.5%±50d Parallel
20.000nF 1pF 1.0%±10d 1.0%±50d ---
200.00nF 0.01nF 0.9%±10d 0.9%±50d ---
2000.0nF 0.1nF 1.0%±10d 1.0%±50d Series
20.000uF 1nF 1.2%±15d 1.2%±50d Series
200.00uF 0.01uF 2.5%±10d 2.5%±50d Series
2000uF 1uF 4%±20d 4%±50d Series
Range Resolution Cx Accuracy DF Accuracy Measurement Mode
200.00pF 0.01pF 3.0%±8d 3.0%±50d Parallel
2000.0pF 0.1pF 1.0%±10d 1.0%±50d ---
20.000nF 1pF 0.9%±10d 0.9%±50d ---
200.00nF 0.01nF 0.8%±10d 0.8%±50d Series
2000.0nF 0.1nF 1.0%±8d 1.0%±50d Series
20.000uF 1nF 2.0%±8d 2.0%±50d Series
200.0uF 0.1uF 4.5%±15d 4.5%±50d Series
Range Resolution Cx Accuracy DF Accuracy Measurement Mode
200.00pF 0.01pF 2.5%±15d 2.5%±50d Parallel
2000.0pF 0.1pF 1.0%±8d 1.0%±50d Parallel
20.000nF 1pF 1.8%±8d 1.8%±50d Parallel
200.00nF 0.01nF 1.5%±10d 1.5%±50d Series
2000.0nF 0.1nF 2.5%±15d 2.5%±50d Series
Profeesional LCR Meter / English
Resistance @ Ta =18 ~ 28
o
C(De)
Frequency = 100 Hz/120 Hz
Frequency = 1kHz
Frequency = 10kHz
Range Resolution Rx Accuracy Measurement Mode
200.00Ω 0.01Ω 1.2%±10d ---
2.0000kΩ 0.1Ω 0.8%±5d ---
20.000kΩ 1Ω 0.9%±5d ---
200.00kΩ 0.01kΩ 0.7%±3d ---
2.0000MΩ 0.1kΩ 1.0%±5d ---
20.000MΩ 1kΩ 2.2%±10d ---
200.0MΩ 0.1MΩ 2.5%±10d —
Range Resolution Rx Accuracy Measurement Mode
20.000Ω 1mΩ 1.2%±10d ---
200.00Ω 0.01Ω 0.8%±5d ---
2.0000kΩ 0.1Ω 0.8%±3d ---
20.000kΩ 1Ω 0.7%±3d ---
200.00kΩ 0.01kΩ 1.0%±5d ---
2.0000MΩ 0.1kΩ 1.5%±10d ---
20.000MΩ 1kΩ 1.8%±10d ---
200.0MΩ 0.1MΩ 6.0%±50d —
Range Resolution Rx Accuracy Measurement Mode
20.000Ω 1mΩ 1.5%±10d ---
200.00Ω 0.01Ω 0.8%±10d ---
2.0000kΩ 0.1Ω 0.9%±5d ---
20.000kΩ 1Ω 0.8%±3d ---
200.00kΩ 0.01kΩ 1.0%±5d ---
2.0000MΩ 0.1kΩ 2.5%±10d ---
20.00MΩ 0.01MΩ 2.8%±10d ---
