Section 7
Section 7Section 7
Section 7
Programming The Alarm System
Programming The Alarm SystemProgramming The Alarm System
Programming The Alarm System
Press the ‘↵’ & ‘-’ Keys simultaneously to enter Alarm Program Mode.
7.1 Setting the High and Low Temperature Alarms.
The LED display shows °
°°
° C
CC
C . AL
ALAL
AL . . Press the ‘↵’ Key to display the High Temperature Alarm,
HI 37
HI 37HI 37
HI 37.5
55
5 . The factory setting is the programmed value +0.5°C. This value can be adjusted using the
‘+’ & ‘-’ Keys, the minimum setting is 0.5°C from set point. Press the ‘↵’ Key to accept the setting
and the Low Temperature Alarm is displayed LO
LOLO
LO 36
3636
36 . 5
55
5 . Press the ‘↵’ Key to accept the setting.
7.2 Setting the CO
2
High and Low Alarms.
Press the ‘+’ Key, the display will show CO2
CO2CO2
CO2 . AL
ALAL
AL . . Press the ‘↵’ Key to display HI
HIHI
HI . 5
55
5 . 5
55
5
Adjustment and the Low Alarm Set point are as described in 1) above.
7.3 Door Open Alarm.
To adjust the time delay after opening the door before the alarm sounds, Press the ‘+’ Key, the
display will show doo
doodoo
doo . rAL
rALrAL
rAL Press the ‘↵’ Key and the ‘+’ & ‘-’ Keys to adjust the time in the
following steps – 15, 30, 45, 60, 75 & 90 seconds, then OFF. Press ‘↵’ to select the preferred value.
Press ‘∗’ to return to the Main Alarm Programming Menu. Press ‘∗’ again to return to the main
display.
7.4 Alarm Duration.
To adjust the length of time which all Alarms are on for. Press the ‘+’ Key, the display shows Per
PerPer
Per .
Iod
IodIod
Iod . Press the ‘↵’ Key and the ‘+’ & ‘-’ Keys to adjust the Alarm on time in the following steps -
OFF, 10 sec, 30 sec, 60 sec, 600 sec, 1 Hr , then ON. Press ‘↵’ to select the preferred value.
Press ‘∗’ to return to the Main Alarm Programming Menu. Press ‘∗’ again to return to the main
display.
7.5 Alarm Arm Time.
This is the length of time that is allowed for the Temperature and CO
2
to recover before the Alarm
System is armed. Press the ‘+’ Key, the display will show dr
dr dr
dr . dEL
dELdEL
dEL Press the ‘↵’ Key and the ‘+’
& ‘-’ Keys to adjust the Alarm Arm time in the following steps – 0.15 Hr (15mins), 0.20, 0.30, 1.00,
then OFF. Press ‘↵’ to select the preferred value.
Press ‘∗’ to return to the Main Alarm Programming Menu. Press ‘∗’ again to return to the main
display.
NB – When set to OFF the Alarm will arm only when programmed set point is reached.
