VX88-18G USER GUIDE
www.rticorp.com
12
CEC Page - User-dened
On the CEC User-dened Page, you can enter custom CEC commands and have these transmitted out of
either an input or output. Please Note: CEC is subject to the support of the sources and displays connected
to the Matrix.
RS-232 Page - Local
The RS-232 page allows you to send commands either out of the local RS-232 port on the Matrix itself, or
via HDBT and out of a compatible HDBT Receiver connected to a display. If the Local radio box is selected,
RS-232 commands will be sent out of the DB9 serial port at the rear of the Matrix. Baud rate and terminator
command as well as Hex or ASCII can be selected.
