RTK 725 Series Instruction Manual

INM725 RTK Series 725 Annunciator
11
LAMP
TEST
MEDIUM WINDOW
VERSION
Typical Medium Window Version
3. System Description & Features
3.1 General
Annunciators are manufactured to meet individual customer's requirements using separate "cells"
which can be assembled in configurations from 1 to 16 cells high and 1 to 16 cells wide as required.
The finished array is “picture framed” using standard lengths of aluminium extrusion. Individual alarm
channels can be displayed in one of three sizes as shown below
Large, Medium & Small Window Sizes
LARGE
WINDOW
VERSION
60 X 60 mm
MEDIUM
WINDOW
VERSION
30 X 60 mm
SMALL
WINDOW
VERSION
30 X 30 mm
