INM725 RTK Series 725 Annunciator

3.2 Window Colours

Systems supplied before June 2013

Each channel is equipped with its own removable bezel, which contains a clear lens, white diffuser,

coloured filter and a laser printed film legend.

Part

Small Window Medium Window Large Window

Bezel

ID-SLC-3WF-B ID-SLC-3WH-B ID-SLC-3WG-B

Clear Lens

ID-SLC-3LF ID-SLC-3LH ID-SLC-3LG

White Diffuser

ID-SLC-3PF-WH ID-SLC-3PH-WH ID-SLC- 3PG-WH

Clear filter

(used with white windows)

ID-SLC-3PF-C ID-SLC-3PH-C ID-SLC- 3PG-C

Red filter

ID-SLC-3PF-R ID-SLC-3PH-R ID-SLC- 3PG-R

Amber filter

ID-SLC-3PF-A ID-SLC-3PH-A ID-SLC- 3PG-A

Yellow filter

ID-SLC-3PF-Y ID-SLC-3PH-Y ID-SLC- 3PG-Y

Blue filter

ID-SLC-3PF-B ID-SLC-3PH-B ID-SLC- 3PG-B

Green filter

ID-SLC-3PF-GD ID-SLC-3PH-GD ID-SLC- 3PG-GD
