RTK 725 Series Instruction Manual

INM725 RTK Series 725 Annunciator
13
Systems supplied after June 2013
In June 2013 RTK simplified the Bezel assembly and removed the need for a diffuser.
Each channel is equipped with its own removable bezel, which contains a clear lens, coloured filter
and a laser printed film legend.
The following part numbers refer to systems supplied after June 2013
Part
Small Window Medium Window Large Window
Bezel ML-7227-S ML-7227-M ML-7227-L
Clear Lens ML-7228-S ML-7228-M ML-7228-L
Red filter ML-7229-S-RD ML-7229-M-RD ML-7229-L-RD
Amber filter ML-7229-S-AM ML-7229-M-AM ML-7229-L-AM
Yellow filter ML-7229-S-YW ML-7229-M-YW ML-7229-L-YW
Blue filter ML-7229-S-BL ML-7229-M-BL ML-7229-L-BL
Green filter ML-7229-S-GN ML-7229-M-GN ML-7229-L-GN
