RTK 725 Series Instruction Manual

INM725 RTK Series 725 Annunciator
15
Systems supplied after June 2013
Each lens assembly has a small slot in the upper ridge of the surround bezel, which allows a flat
blade terminal screwdriver to be used to gently lever the assembly from the annunciator.
Once the assembly has been removed the lens, coloured filter and film legend can be accessed by
gently pushing outwards on the side of the inside face of the bezel to allow the lens to clear the
associated moulding tabs.
TAHH-32A
TEMPERATURE
ALARM
HIGH-HIGH
COLOURED FILTER
FILM LEGEND
SLOT TO LEVER
THE BEZEL OUT
BEZEL
LENS
3.5 Lamp Or LED Illumination
Lamp Versions
All units are suitable for either 28V - 10 mm wedge based lamps part no. LP-28-004
LED Assemblies
RTK use LED assemblies as standard, which plug into the standard lamp socket, as they offer lower
power consumption and offer a maintenance free solution.
RTK provide white LED’s as standard throughout the range.
