Einbau- und Betriebsanleitung 3447-8010
Installation and operating instructions
Instructions de montage et de service
03.2012 Seite 19 von 80
12
+Warning in case of exchange against RE3446
If the positioner RE3447 is used as replacement for RE3446,
Please note: There is no additional 24VDC supply required for the
feedback signal output.
Æ The output terminal: 66, 65 are active!
Non compliance can lead to the destruction of the positioned
13
Installation + electrical connections
13.1 Feedback potentiometer
Precondition for the operation of the positioner is the correct installation and adjustment of the feedback potentiometer
in the actuator.
+ Installation and operating instructions Feedback potentiometer see appendix
