Ruby Tech FGS-2824 User Manual

FGS-2824 User Manual
Publication date: July, 2005
Revision A1
6
1-4. View of FGS-2824 L2 Managed Switch
1-4-1. User Interfaces on the Front Panel (Button, LEDs and Plugs)
There are 8 TP Gigabit Ethernet ports and 16 SFP fiber ports for optional
removable modules on the front panel of the switch. LED display area, locating on
the left side of the panel, contains a Power LED, which indicates the power status
and 24 ports working status of the switch.
Fig. 1-1 Full View of FGS-2824
Fig. 1-2 Front View of FGS-2824
Power Indication LED
Gigabit Ethernet Port
TP Port Status I
ndication LED
s
RESET B
utton
:
RESET button is used to
initialize or reset the
management system.
SFP Fiber Port
Fiber Port Status Indication LED
s
