FGS-2824 User Manual
Publication date: July, 2005
Revision A1
8
1-5. View of the Optional Modules
In the switch,1000Mbps SFP Fiber transceiver is used for high-speed
connection expansion; nine optional SFP types provided for the switch are listed
below:
1000Mbps LC, MM, SFP Fiber transceiver (SFP.0LC.202)
1000Mbps LC, SM 10km, SFP Fiber transceiver (SFP.0LC.212.10)
1000Mbps LC, SM 30km, SFP Fiber transceiver (SFP.0LC.212.30)
1000Mbps LC, SM 50km, SFP Fiber transceiver (SFP.0LC.212.50)
1000Mbps BiDi LC, type 1, SM 20km, SFP Fiber WDM transceiver
(SFP.0BL.621.201)
1000Mbps BiDi LC, type 2, SM 20km, SFP Fiber WDM transceiver
(SFP.0BL.621.202)
1000Mbps LC, SM 10km, SFP Fiber transceiver with DDM
(SFP.DLC.212.10)
Fig. 1-4 Front View of 1000Base-SX/LX LC, SFP Fiber Transceiver
Fig. 1-5 Front View of 1000Base-LX BiDi LC, SFP Fiber Transceiver
