Chapter 5 – Configuring Class of Service
DSCP to CoS Mapping Menu
The DSCP to CoS Mapping menu is accessible from the Classes Of Service menu.
Figure 30: TOS DSCP to CoS Mapping
CoS
This menu maps the TOS DSCP from a IP frame to a CoS.
CoS Access Priorities Menu
The CoS Access Priorities menu is accessible from the Classes Of Service menu.
Figure 31: CoS Access Priorities Menu
My Switch DSCP to CoS Mapping Admin Access
DSCP CoS
0 Normal
1 Normal
2 Normal
3 Normal
4 Normal
5 Normal
6 Normal
7 Normal
8 Normal
9 Normal
More below ...
My Switch CoS Access Priorities Admin Access
Port Normal Access Priority High Access Priority
1 0 4
2 0 4
3 0 4
4 0 4
5 0 4
6 0 4
7 0 4
8 0 4
<CTRL> Z-Help S-Shell>
Normal Access Priority
When frames that were originally received untagged are transmitted from a tagged
port the switch will insert an 802.1Q VLAN tag priority field based upon the
frame’s CoS. The port will insert this parameters value when the frame is
configured for normal priority CoS.
High Access Priority
The port will insert this parameters value when the frame is configured for high
priority CoS.
