Hardware Installation and Reference Guide Product Overview
4
8 copper ports. Supports 8 10/100/1000 M (copper) fast Ethernet ports and
automatic recognition of network cables and cross-over cables.
By default, ports LAN0, LAN1, LAN2, LAN3, LAN4 and LAN5 are LAN ports,
while ports WAN0 and WAN1 are WAN ports.
Ports LAN1, LAN2, LAN3, LAN4, LAN5 and WAN1 support WAN/LAN
switchover.
2 SFP ports. Supports 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-
LX20/LH40-BIDI SPF modules.
By default, the SFP ports are WAN ports, and support WAN/LAN switchover.
1 management port (in bridging mode)
1 hardware disk module (optional)
Hot swapping of hardware disk module: not support
Ethernet: 10Base-T/100Base-TX/1000Base-TX, 1000BASE-SX/LX/ZX,
10GBASE-SR/LR/ZR
440 mm x 43.6 mm x 200 mm (excluding the foot pad)
Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 10% to 90% RH (non-condensing)
Instruction
Not all USB disks are supported. The Kingston USB disk with FAT 32 is recommended.
Note
Please avoid the vibration and collision in the process of moving and usage.
To power off the device with the hard disk module inserted, please turn off the power button. Do not
remove the power cable until the PWR LED turns off, or else the hardware disk will be damaged.
