Hardware Installation and Reference Guide Starting and Configuring the Enterprise-class Router
22
Turn on the power switch of the enterprise-class router and set the power switch to "ON" position.
3. Checks after Power-on
After the enterprise-class router is powered on, check the following items:
Whether the ventilation system works normally
Checking procedure: After power-on, you can hear the fan working; put your hand nearby the vent hole of
enterprise-class router to feel the airflow.
Whether the LED indicators on the front panel of the enterprise-class router works normally.
Checking procedure: Refer to the section of indicators description about each product in the first chapter
“Product Overview”.
Whether the configuration terminal displays normally
Checking procedure: After the enterprise-class router is powered on, the terminal will display the software
loading information of the enterprise-class router.
4.1.3 Starting Process
The following information will be displayed when the enterprise-class router is started for the first time:
***********************************************
Boot 1.3.12-00503-ga15871f (Build time: Nov 25 2015 - 10:13:23)
DRAM: 2 GiB
NAND: 512 MiB
Flash: 8 MiB
SETMAC: Setmac operation was performed at 2016-01-06 11:03:10 (version: 11.0)
Press Ctrl+C to enter Boot Menu
Creating 1 MTD partitions on "nand0":
0x000000000000-0x000001000000 : "mtd=0"
UBI: attaching mtd2 to ubi0
UBI: physical eraseblock size: 131072 bytes (128 KiB)
UBI: logical eraseblock size: 129024 bytes
UBI: smallest flash I/O unit: 2048
UBI: sub-page size: 512
UBI: VID header offset: 512 (aligned 512)
UBI: data offset: 2048
UBI: attached mtd2 to ubi0
UBI: MTD device name: "mtd=0"
UBI: MTD device size: 16 MiB
UBI: number of good PEBs: 128
UBI: number of bad PEBs: 0
UBI: max. allowed volumes: 128
UBI: wear-leveling threshold: 4096
UBI: number of internal volumes: 1
UBI: number of user volumes: 1
UBI: available PEBs: 9
UBI: total number of reserved PEBs: 119
