Hardware Installation and Reference Guide Product Overview
9
Voltage
100–240 V; 50/60 Hz
Power Consumption
Less than 20 W
Working Environment
Temperature: -5°C to 45°C (23°F to 113°F)
Humidity: 10% to 90% RH (non-condensing)
Instruction
Not all USB disks are supported. The Kingston USB disk with FAT 32 is recommended.
3. LED Indicators of Ruijie RG-NBR6120-E Enterprise-class Router
Table 1-8 LED Indicators of Ruijie RG-NBR6120-E Enterprise-class Router
LED Indicators
Working Status
PWR
Solid green indicates the device is receiving power properly.
Off indicates the power module is faulty or not powered on.
SYS
Blinking green indicates the system is being initialized.
Solid green indicates system initialization has completed.
Link/ACT
Solid green indicates that the port is connected at 10/100/1000 Mbps.
Blinking green indicates that the port is receiving or transmitting traffic at
10/100/1000 Mbps.
Speed
Solid orange indicates that the port is connected at 1000 Mbps.
Off indicates that the port is connected at 10/100 Mbps.
