Ruijie Reyee RG-NBR-E Series Hardware Installation And Reference Guide

Hardware Installation and Reference Guide Product Overview
2
Ports LAN1, LAN2, LAN3, LAN4, LAN5 and WAN1 support WAN/LAN
switchover.
2 SFP ports. Supports 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-
LX20/LH40-BIDI SPF modules.
By default, the SFP ports are WAN ports, and support WAN/LAN switchover.
1 management port (in bridging mode)
1 console port
2 USB ports
Hardware Disk Module
1 hardware disk module (optional)
Hot Swapping
Hot swapping of hardware disk module: not support
Interface Standard
Ethernet: 10Base-T/100Base-TX/1000Base-TX, 1000BASE-SX/LX/ZX,
10GBASE-SR/LR/ZR
Console port: RS-232
Dimension (W x H x D)
440 mm x 43.6 mm x 200 mm (excluding the foot pad)
Voltage
100–240 V; 50/60 Hz
Power Consumption
Less than 25 W
Working Environment
Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 10% to 90% RH (non-condensing)
Instruction
Not all USB disks are supported. The Kingston USB disk with FAT 32 is recommended.
Note
 Please avoid the vibration and collision in the process of moving and usage.
 To power off the device with the hard disk module inserted, please turn off the power button. Do not
remove the power cable until the PWR LED turns off, or else the hardware disk will be damaged.
3. LED Indicators of Ruijie RG-NBR6205-E Enterprise-class Router
Table 1-2 LED Indicators of Ruijie RG-NBR6205-E Enterprise-class Router
LED Indicators
Working Status
PWR
Solid green indicates the device is receiving power properly.
Off indicates the power module is faulty or not powered on.
SYS
Blinking green indicates the system is being initialized.
