Ruijie Reyee RG-NBR-E Series User Manual

Cookbook Configuration
117
Configuration Item
Parameter
Source IP Range
Access control for the packets from the designated source IP address. You can
enter a single IP address (example: 1.1.1.1), a subnet or mask length
(example: 1.1.1.0/24), a subnet or mask (example: 1.1.1.0/255.255.255.0) or
any. Enter a source IP range and click Add to enter another range.
Dest IP Range
Access control for the packets to the designated destination IP address. You
can enter a single IP address (example: 1.1.1.1), a subnet or mask length
(example: 1.1.1.0/24), a subnet or mask (example: 1.1.1.0/255.255.255.0) or
any. Enter a source IP range and click Add to enter another range.
Transport Protocol
Access control for the packets of the selected protocol.
Select Effective Time
Indicate the time span in which the policy takes effect. Click Time Span
Management to select a time span.
(5) Configure the ACL policy according to the following information and click Finish. If you select IP Range for
the policy configuration mode, skip this procedure.
a Click Select to select configured ACL policy. If there is no available ACL policy, click Manage to create
an ACL policy.
