Weight
4.3 kg (9.48 lbs.)
Appearance
The front panel of the RG-S5310-48GT4XS-E Ethernet switch provides 48 10/100/1000Base-T Ethernet ports, four 10GE SFP+ ports, one
management port, one Console port and one USB port. The back panel has two power supply module slots.
Figure 1-13 RG-S5310-48GT4XS-E Switch Appearance
Front Panel
Figure 1-14 Front Panel of RG-S5310-48GT4XS-E
1. System Status LED
2. Management Port LED
3. PWR1 Status LED
4. PWR2 Status LED
5. USB Port
6. Console Port
7. Management Port
8. 10/100/1000Base-T Ethernet Port
9. 10GE SFP+ Port
10. Port LED
Back Panel
Figure 1-15 Back Panel of RG-S5310-48GT4XS-E
