Hardware Installation and Reference Guide Product Overview
18
2. Management Port LED
3. USB Port
4. Console Port
5. Management Port
6. 10/100/1000Base-T Ethernet Port
8. GE SFP Port LED
9. 10GE SFP+ Port LED
10. 10GE SFP+ Port
Back Panel
Figure 1-19 Back Panel of RG-S5300-48GT2SFP2XS-E
Power Supply
The RG-S5300-48GT2SFP2XS-E switch has a built-in power supply module. The back panel has an AC power plug.
Cooling
The RG-S5300-48GT2SFP2XS-E switch adopts a left-to-right and front-to-right airflow to ensure normal operation. Maintain a minimum
clearance of 100 mm (3.94 in.) around the device for air circulation.
Figure 1-20 Airflow Direction
