Hardware Installation and Reference Guide Product Overview
28
All RJ45 ports are PoE+ capable and each port provides up to 30 W of power.
Maximum PoE Output: 370 W
The PoE+ port is compliant with both the PoE (IEEE802.3af) and PoE+ (IEEE802.3at) standards.
The maximum number of PoE devices supported by the switch is determined by the available
PoE consumption of the switch and the actual PoE consumption of each device.
The PoE port is compliant with Alternative A.
With PoE Full Load: < 410 W
0ºC to 45ºC (32ºF to 113 ºF) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum
operating temperature decreases by 1°C (1.8°F) every time the altitude increases by 220 m (721.78
ft.).
-40ºC to 70ºC (-40ºF to 158ºF)
10% to 90% RH (non-condensing)
0 to 5000 m (3.11 miles) above the sea level
5% to 95% RH (non-condensing)
Fan Speed Control
Fan Fault Alarming
Safety Regulation
Compliance
442 mm x 220 mm x 43.6 mm (17.40 in. x 8.66 in. x 1.72 in.)
Appearance
The front panel of the RG-S5300-24GT2SFP2XS-P-E switch provides 24 10/100/1000Base-T Ethernet ports (PoE+ capable), two GE SFP
ports, and two 10GE SFP+ ports (The speed is 1000 Mbps by default and can be improved to 10 Gbps if you purchase a license. Without
a license, the port can make a successful link only when the peer end speed is 1000 Mpbs. If configured as a VSL port, the port supports
a speed of 10 Gbps without the license), one management port, one Console port and one USB port. The back panel has an AC power
plug.
Figure 1-29 RG-S5300-24GT2SFP2XS-P-E Switch Appearance
