Ruijie RG-S5310-E Series

Hardware Installation and Reference Guide Product Overview
40
RTC
supported
PoE
Not supported
Power Consumption
< 85 W
Operating Temperature
0ºC to 45ºC (32ºF to 113 ºF) at a height below 1800 m (1.12 miles) above the sea level
At a height ranging from 1800 m (1.12 miles) to 5000 m (3.11 miles) above the sea level, the maximum
operating temperature decreases by 1°C (1.8°F) every time the altitude increases by 220 m (721.78
ft.).
Storage Temperature
-40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fan Speed Control
Fan Fault Alarming
Temperature Alarming
Supported
EMC Certification
GB/T 9254.1
Safety Regulation
Compliance
GB 4943.1
Dimensions
(W x D x H)
442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.)
Weight
4.2 kg (9.26 lbs.)
Appearance
The front panel of the RG-S5310-24SFP4XS-E switch provides 24 GE SFP ports, four 10GE SFP+ ports, one management port, one
Console port and one USB port. The back panel has two power supply module slots.
Figure 1-41 RG-S5310-24SFP4XS-E Switch Appearance
Front Panel
Figure 1-42 Front Panel of RG-S5310-24SFP4XS-E
