RunCam Thumb 2 - Remote Control

Here we take Flight Controller Speedy Bee-F7 for an example
Solder the wires of TypeC control cable to the pads on
Speedy Bee F7 V3, with Power wire to 5V pad, GND wire
to GND pad, Tx wire to R3 pad and Rx wire to T3 pad.
Type-C Control cable instruction
Remote Control via UART (Recommended)
10
Power wire
It suppos external power input of DC 5V.
Ground
Power ground wire / Remote control signal ground wire
Video
It can be soldered to VI pad of Flight Controller or Video
In pad of Video Transmitter to transmit video signal to VTX.
TX
It can be soldered to a R3 pad or other spare UART of Flight
Controller to achieve remote control for camera.
RX
It can be soldered to a T3 pad or other spare UART of Flight
Controller to achieve remote control for camera.
Use BetaFlight to congure, setting the UART3 of SpeedyBee
F7 V3 as RunCam device.
Remote Control
.
.
