Here we take Flight Controller Speedy Bee-F7 for an example
Solder the JST 1.25*3pin wires to the
pads on Speedy Bee F7 V3, with
Power wire to 5V pad,
GND wire to GND pad,
PWM wire to M6 pad.
Find the Modes tab at the BetaFlight, and nd CAMERA CONTROL.
Set the value for the camera (select AUX by yourself), and the
range is 1900-2100.
For example:
Congure at Modes
Please choose your Model on the
controller, then access to the
MIXER inteace and assign the
channel to the switches. Here we
take Radiomaster TX12 as an
example, assigning the channel
CH5 to SE position.
Assign the channels to the switch of the controller
Power on Thumb 2 and the Flight Controller
·Set the SE to the bottom, the camera stas/stops recording
Test
PWM Remote Control
