Runxin N77B1 User Manual

MODEL: 63518-N77A1 /63618-N77A3/ 53518-N77B1
29
2) Injector Parameter Table
Inlet Pressure
Draw Rate（L/M）
MPa
7701
Coffee
7702
Pink
7703
Yellow
7704
Blue
7705
White
0.20
18.72
25.83
35.52
42.27
49.25
0.25
26.83
32.42
45.59
57.02
63.58
0.30
32.08
39.41
51.16
64.90
72.37
0.35
37.56
49.79
59.17
70.75
79.85
0.40
42.14
54.77
63.77
76.46
85.86
3) Configuration for Standard Injector and Drain Line Flow Control
Tank
Dia.
mm
Injector
Model
Injector
Color
Draw Rate
Slow
Rinse
DLFC&
Holes
Quantity
Backwash /
Fast Rinse
L/m
L/m
L/h
700
7701
Coffee
32
20
0
7.5
750
7702
Pink
39.5
26.5
0
7.5
800
7702
Pink
39.5
26.5
1×φ6
9.2
850
7703
Yellow
51.2
33.3
1×φ6
9.2
900
7703
Yellow
51.2
33.3
2×φ6
10.2
1000
7704
Blue
64.9
42
3×φ6
11.2
1050
7705
White
72.4
48.7
4×φ6
13
Remark:
 Above data for the product configuration and relevant
characteristics are only for reference. When put in practice, please
subject to the different requirements of raw water hardness and
application.
 Above parameter is tested under 0.3MPa inlet pressure.
 Holes quantity is the holes number on DLFC. Diameter of hole is
φ6, the number refer to above table.
