MH 3 Beam user manual 29
DMX protocol
Channel Value Function
1
1-255 Pan 0°~540°
2
1-255 Pan (fine control)
3
1-255 Tilt 0°~270°
4
1-255 Tilt (fine control)
5
1-255 Pan/tilt speed – fast-slow
6
0-29
30-39
40-49
50-59
60-69
70-79
80-89
90-99
100-109
110-119
120-129
130-139
140-149
150-159
160-169
170-179
180-189
190-199
200-209
210-219
220-229
230-239
240-255
Function
No function
Dimmer conventional mode
Dimmer linear mode
Pan/tilt fast mode
Pan/tilt normal mode
Blackout during pan & tilt
Disable blackout during pan & tilt
Blackout during color change
Disable blackout during color change
Blackout during gobo change
Disable blackout during gobo change
Lamp on
Pan/tilt reset
Color reset
Gobo reset
Shutter/prism/rotating prism reset
No function
Frost/focus/zoom reset
Reset all
Blackout during pan/tilt or color/gobo change
Disable blackout during pan/tilt or color/gobo change
Lamp off
No function
7
0-7
8-15
16-23
24-31
32-39
40-47
Pan/tilt macros
Off
Macro 1
Macro 2
Macro 3
Macro 4
Macro 5
