Installation
Water drainage
• The water outlet hose should be mounted at a height of minimum 60 cm,
maximum 80 cm from the ground.
• The end of the water outlet hose can be fitted directly to the drainage
hole on the back side of the washer.
• When installing the outlet hose, secure it with a string or tie extensions
(not included).
• Never attempt to extend the water outlet hose by adding extra parts.
• If the outlet hose is too long, do not force it back into the washer.
This will cause abnormal noise and damage to the product.
• Diagram below illustrates installation depending on water supply and waste
outlet.
10cm
Do not insert drain hose more
than10cm (100mm) down the
waste outlet pipe.
