Door reversal & Bulb replacement
6
For Customer Services & Spare Parts please call 0845 208 8750
Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm or visit us at
www.productcareuk.com
Bulb replacement
To replace the internal refrigerator bulb the required rating is: 10W.
Unplug the appliance
Remove bulb cover – see image 1 and 2 below
Unscrew the light bulb by turning anti-clockwise and replace with
new bulb – see the image 3 below.
1 2
3
Door reversal
Remove the screw covers on the top of the fridge freezer. There are two screws at the back
of the lid and two at the front, remove all four screws. Remove the three screws on the top
of the freezer door hinge. Remove the washer, nut and hinge pin.
Remove the freezer door.
Remove the two screws from the middle hinge and remove the fridge door.
Underneath the fridge, unscrew the adjustable foot, remove the three screws, the nut, the
washer, the lower hinge, and the bottom hinge pin. Transfer these parts to the other side
of the fridge, placing them in a symmetrical position to where they were removed. Build
the hinges on the left side of the fridge freezer, as they were removed from the right side.
Fit the lid to the top of the fridge freezer, replacing the four screws.
For assistance with this or any issues please contact the service team on 0845 208 8750
