2.0 GENERAL INFORMATION
General Information
Unit Specications
The Air Conditioning Contractors of America
(ACCA) Manual J method of load calculation is one
recognized procedure for determining the heating
and cooling load.
After the proper equipment combination has
been selected, satisfying both sensible and latent
requirements, the system must be properly installed.
Only then can the system provide the comfort it was
designed to provide.
There are several factors that installers must
consider.
• Outdoor unit location
• Indoor unit blower speed and airflow
• Proper equipment evacuation
• Supply and return air duct design and sizing
• Refrigerant charge
• System air balancing
• Diffuser and return air grille location and sizing
IMPORTANT: Excessive use of elbows
in the refrigerant line set can produce excessive
pressure drop. Follow industry best practices for
installation. Installation and commissioning of
this equipment is to be performed by trained
and qualified HVAC professionals. For technical
assistance, contact your Distributor Service
Coordinator.
2.5 Importance of Proper
Indoor/Outdoor Match-Ups
To assure many years of reliable operation and
optimum customer comfort and to assure the
outdoor unit warranty remains valid, an air-handler
model or indoor coil/furnace combination should be
selected that is properly matched to the outdoor unit.
This is especially critical for heat pump systems to
assure proper refrigerant charge balance between
the cooling and heating modes. The recommended
approach is to select an air-handler or indoor coil
and gas furnace that has an AHRI match with the
outdoor unit. Refer to the AHRI directory at www.
ahridirectory.org to confirm the air-handler and
outdoor unit are a certified combination in the AHRI
Directory.
2.6 Checking Product
Received
Upon receiving unit, inspect it for any shipping
damage. Claims for damage, either apparent or
concealed, should be filed immediately with the
shipping company. Check model number, electrical
characteristics, and accessories to determine if they
are correct. Check system components (indoor coil,
outdoor unit, air handler/furnace, etc.) to make sure
they are properly matched.
2.7 Compressor Break-In
Notice
Prior to agency testing, system must be operated
for 20 hours at 115ºF [46.1ºC] outdoor ambient
temperature with 80ºF [26.7ºC] dry bulb 75ºF
[23.9ºC] wet bulb indoor ambient temperature to
break the compressor in.
2.8 General
This unit RD17A is a PARTIAL UNIT AIR
CONDITIONER, complying with PARTIAL UNIT
requirements of this Standard, and must only be
connected to other units that have been confirmed
as complying to corresponding PARTIAL UNIT
requirements of this Standard, UL 60335-2-40/CSA
C22.2 No. 60335-2-40, or UL 1995/CSA C22.2 No
236.
The appliance is not to be used by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction.
Children being supervised not to play with the
appliance.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or qualified
person in order to avoid a hazard.
The construction of the refrigerating system must
comply with the requirements of ISO 5149-2.
This is the partial unit, need to consider the
construction of refrigerating system with
requirements of ANSI/ASHRAE 15 (USA) and CSA
B52 (Canada) when it is used with the final product.
