ryan 744865D - Specifications

16
REN-O-THIN
SPECIFICATIONS
SPECIFICATIONS
Chassis:........... 12 gauge steel, formed and welded
Reduction:............................. 1.33:1 (engine to reel)
Wheelbase:...........14 5/8" (371 mm) at level position
Reel Speed:.............................................. 2700 RPM
Cutting Width:...................................... 18" (457mm)
Cutting Depth:....................................... 7/8" (22mm)
Blade Adjustment:... 1" (25mm) above ground level
to 7/8" (22mm) below ground level
Weight (less reel):...........................106 lbs. (48 Kg.)
Touch-up Paint: .5l spray can P/N: 65334
Engines:
Starter......................................... Recoil, on/off switch
Governor.................................... 3600 RPM, no load
Model 744865D.......Briggs & Stratton Model 121520
Type 0120, Trim B8
4 cycle 6.5 H.P.
Aluminum cylinder with cast iron
sleeve
Model 744877A.........Honda Model GX160
Type K1QX2
4 cycle 5.5 H.P.
