Ryobi AP1301 Repair Sheet

RYOBI 13 in. PLANER – MODEL NUMBER AP1301
6
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your PLANER or when ordering repair parts.
PARTS LIST FOR FIGURE B
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 089170101106 POWER CORD ........................................................................ 1
2 089170101107 STRAIN RELIEF (6B3-2S) ........................................................ 1
3 827767 CORD CLAMP ......................................................................... 1
4 820240-7 * SCREW (M5 X 20 mm PAN HD.) ............................................. 2
5 089170101110 MOTOR HOUSING (REAR) ..................................................... 1
6 827740 FOAM GASKET ....................................................................... 1
7 827797
SPECIAL SCREW ................................................................... 1
8 089170101113 * SCREW (M4 X 12 mm PAN HD.) ............................................. 4
9 089170101114 SWITCH SOCKET ................................................................... 1
10 089170101115 SWITCH (HY18-13) (INC. KEY NO. 11) ................................... 1
11 089170101116 SWITCH KEY ........................................................................... 1
12 089170101117 MOTOR PIVOT ROD ............................................................... 1
13 820257-1 * SCREW (M5 X 8 mm PAN HD.) ............................................... 1
14 089170101119 * SPRING WASHER (M5) ........................................................... 1
15 827812 LEAD WIRE WITH TERMINAL (300 mm + 3 mm) ................... 1
16 813314-8 LOCK WASHER (M5) .............................................................. 1
17 828946 * SCREW W/WASHER (M4.2 X 20 mm) .................................... 4
18 827707 MOTOR END CAP .................................................................. 1
19 820510-6 SPRING WASHER ................................................................... 1
20 820722-3 BALL BEARING (6201LLB) ...................................................... 2
21 089170101126 ARMATURE ASSEMBLY (INC. KEY NO. 20) .......................... 1
22 827706 SLEEVE ................................................................................... 1
23 828947 * SCREW W/WASHER (M4.8 X 75 mm) .................................... 2
24 089170101129 FIELD ASSEMBLY (INC. KEY NO. 22) .................................... 1
25 827809 BRUSH HOLDER ................................................................... 2
26 827811 BRUSH AND SPRING ASSEMBLY ......................................... 2
27 827810 BRUSH CAP ........................................................................... 2
28 089170101133 MOTOR HOUSING (FRONT) ................................................... 1
29 826551-1 RETAINING RING (RTW32) ..................................................... 1
30 821065-3 * SCREW (M5 X 12 mm HEX SOC.) .......................................... 2
983000828 OPERATOR’S MANUAL
983000828R REPA
IR SHEET (REV:01)
01-27-0
6
