Page 42
Key
No. Description Quan.
Key
No. Description Quan.
* Item 96 includes parts 42, 78, 100 through 105, and 111.
110 Hang Tag.................................................... 1
111 Back-Up Plate ............................................ 1
112 Screw (10-24 x 3/4 in. Flat Hd.) ................. 3
113 Bolt Holder.................................................. 1
114 Rear Switch Cover...................................... 1
115 Needle Roller .............................................. 1
116 Screw (8-16 x 3/8 in. Pan Hd.) ................... 4
117 Switch Cover............................................... 1
118 Switch Cover Label..................................... 1
119 Switch ......................................................... 1
120 Switch Base ................................................ 1
121 Latch ........................................................... 1
92 End Plug R1 (right rear) ............................. 1
93 End Plug R2 (left rear) ............................... 1
94 Rip Fence Assembly .................................. 1
95 Blade Guard Assembly............................... 1
96 *Accessory Table Assembly ........................ 1
100 Accessory Table ......................................... 1
101 Handle Shaft............................................... 1
102 Handle ........................................................ 1
103 Spring Plate ................................................ 1
104 Retaining Extension ................................... 1
105 Hex Nut (1/4-20) .........................................1
107 Washer ....................................................... 1
108 Spacer ........................................................ 1
RYOBI 10 in. (254 mm) TABLE SAW - MODEL NO. BT3000
PARTS LIST-FIGURE 59-CONT'D
WARNING:
Improper electrical repair of the table saw can result in damage to the drive system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool require safety testing and should only be performed by a
Ryobi Authorized Service Center.
