14
RYOBI 10 in. (254 mm) TABLE SAW - MODEL NO. BTS20R
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
TABLE SAW or when ordering repair parts.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
* Standard Hardware Item – May Be Purchased Locally
A131010101 COMPLETE MOTOR ASSEMBLY
1 0131010602 ARBOR .......................................................1
2 415030001 KEY (3 x 3 x 10 mm) ....................................1
3 420010003 * BALL BEARING (6002LU, Z) .......................1
4 0101010505 BEARING BUSHING ....................................1
5 413011001 * C-CLIP (S15) ................................................1
6 0131011001 REDUCTION GEAR .....................................
1
7 413011009 * C-CLIP (S13) ................................................
1
8 420110003 * NEEDLE BEARING (HK0910) ....................1
9 0131010101 GEAR BOX ...................................................1
10 420010001 * BALL BEARING (6201LLU CM,5C) .............1
11 A131010301 ARMATURE ASSEMBLY ..............................1
12 0181010344 INSULATION PLATE ....................................1
13 0181010307 INSULATION PLATE ....................................1
14 420010004 * BALL BEARING (6200LU CM,5C) ...............1
15 0131010202 BAFFLE ........................................................1
16 410462002 * SCREW AND STAR WASHER (M5 x 60 mm) ..... 2
17 A131010401 FIELD ...........................................................1
PARTS LIST FOR FIGURE F
Key Part
No. Number Description Qty.
Key Part
No. Number Description Qty.
18 451020002 WIRE NUT ...................................................
2
19 0131010703 MOTOR WIRE ..............................................1
20 0131010201 MOTOR HOUSING ......................................1
21 410271701 * SCREW AND WASHER
(3/16-32UNF
x 1-3/8 in.) ..............................4
22 410071004 * SET SCREW (M5 x 10 mm) .........................2
23 0502020221 BRUSH HOLDER ASSEMBLY .....................2
24 0502025002 BRUSH ASSEMBLY ....................................
2
25 0602200209 BRUSH CAP ................................................2
26 451010003 STRAIN RELIEF ...........................................1
27 0301030202 WIRE CLAMP (5/16 in.) ...............................1
28 410131002 * SCREW (M4 x 8 mm) ...................................1
29 412041002 * LOCK WASHER (M4) ...................................1
30 A131010501 ARBOR SHAFT ASSEMBLY ........................1
983000428 OPERATOR'S MANUAL
01-04-07
(REV:04)
