16
RYOBI 10 in. (254 mm) TABLE SAW - MODEL NO. BTS20R
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
TABLE SAW or when ordering repair parts.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
* Standard Hardware Item – May Be Purchased Locally
1 0101140203 HANDWHEEL BOLT ....................................2
2 0131010208 HANDWHEEL HANDLE ...............................1
3 0131010207-35 BEVEL HANDWHEEL CAP ..........................
1
4 412011712 * FLAT WASHER (1/4
x 13 x 1.5) .................... 1
5 0131010206 FRONT HANDWHEEL ................................. 1
6 410132719 * SCREW (8-32 x 1-3/16 in.) ..........................1
7 411072702 * LOCK NUT (1/4-20) .....................................1
8 0131010805 SCREW ROD .............................................1
9 0131010815 * TORQUE SCREW (5/16-18 x 1/2 in.) ...........2
10 410161004 * LOCK SCREW (M6 x 25 mm) ......................4
11 0131010203-39 CABINET ..................................................... 1
12 0131010816 * TORQUE SCREW (5/16-18 x 1-1/4 in.) .......2
13 0131010217-39 CABLE MANAGEMENT (LEFT) .................... 1
14 451010003 STRAIN RELIEF ........................................... 1
15 0131010222-39 CABLE MANAGEMENT (RIGHT) ................. 1
16 410191005 * SCREW (M4 x 20 mm PAN HD.) .................. 8
17 410031710 * CARRIAGE BOLT (5/16-18 x 1-1/2 in.) ........1
18 0131010212-39 FENCE HANGER (REAR) ............................. 1
19 0131010240 BLADE STORAGE KNOB ............................1
20 0171010216 BLADE STORAGE SPACER ........................ 1
PARTS LIST FOR FIGURE G
Key Part
No. Number Description Qty.
Key Part
No. Number Description Qty.
21 0131010211-39 FENCE HANGER (FRONT) ..........................
1
22 410451703 * SCREW (8-16 x 3/4 in.) ................................7
23 984406-001 SWITCH .......................................................
1
24 0131010702 POWER CORD ............................................
1
25 0131010209 SWITCH BOX ..............................................1
26 0131010210 CORD CLAMP ............................................. 1
27 9131015330201 WARNING LABEL ........................................ 1
28 0301030202 WIRE CLAMP (5/16) ....................................4
29 410451701 * SCREW (8-16 x 1/2 in.) ................................5
30 410132728 * SCREW (1/4-20 x 3/8 in.) ............................2
31 0131010328 PLATE .......................................................... 1
32 414011021 * SPRING PIN (M4 x 24 mm) .........................1
33 0131010926 BALL ............................................................1
34 0131010320 REINFORCE PLATE .....................................1
35 984406-003 SWITCH KEY ............................................... 1
36 412015087 * WASHER (D11 x 26 x 2T) ............................1
37 9131015335706 LOCK LABEL ............................................... 1
38 9131015335705 UNLOCK LABEL .......................................... 1
39 9131015333102 DATA PLATE (BTS20R) ................................1
