18
RYOBI 10 in. (254 mm) TABLE SAW - MODEL NO. BTS20R
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
TABLE SAW or when ordering repair parts.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
* Standard Hardware Item – May Be Purchased Locally
A131010801 MITER GAUGE ASSEMBLY
1 A131015202 KNOB ..................................................................................................... 1
2 412012705 WASHER ................................................................................................
1
3 412080702 NYLON WASHER ..................................................................................
1
4 9131015330102 LOGO LABEL .........................................................................................
1
5 0131010109-94 MITER GAUGE HEAD ..........................................................................
1
6 411012704 HEX NUT ...............................................................................................
3
7 410132734 SCREW .................................................................................................. 3
8 9131015330304 MITER SCALE LABEL ...........................................................................
1
9 0131010928 MITER SLIDER WASHER ...................................................................... 1
10 410102014 * SCREW (M6
x 8 mm) ............................................................................. 1
11 0101010917 CENTER PIN ..........................................................................................
1
12 410332701 SCREW ..................................................................................................
1
13 0131010329 MITER INDICATOR ................................................................................ 1
14 0131010110 INDICATOR DECK ................................................................................. 1
15 0101010918 INDEX PIN ............................................................................................. 1
16 0131011807 BAR ....................................................................................................... 1
17 410102701 SCREW .................................................................................................. 2
PARTS LIST FOR FIGURE H
Key Part
No. Number Description Qty.
