RYOBI 10 in. (254 mm) TABLE SAW - MODEL NO. BTS20R
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
TABLE SAW or when ordering repair parts.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
* Standard Hardware Item – May Be Purchased Locally
PARTS LIST FOR FIGURE A
Key Part
No. Number Description Qty.
A131013901 OUTFEED SUPPORT ASSEMBLY
1 0131010314 OUTFEED SUPPORT .............................................................................
1
2 410551701 * SCREW (1/4-20
x 1/2 in.) .......................................................................2
3 0131010809 OUTFEED SUPPORT ROD ....................................................................
2
4 410182001 * STOP SCREW (M4 X 7
mm) .................................................................. 1
