5
RYOBI 10 in. (254 mm) TABLE SAW - MODEL NO. BTS20R
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
TABLE SAW or when ordering repair parts.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
* Standard Hardware Item – May Be Purchased Locally
A131011001 BLADE GUARD ASSEMBLY
1 411105701 * PUSH NUT (5/16
in.) ............................................................................. 4
2 414050003 * PIN (5/16
in. x 1-1/4 in.) ........................................................................ 1
3 0131010303 ARM ......................................................................................................
1
4 0181010902 TORSION SPRING ................................................................................
1
5 0131010204 BLADE GUARD .....................................................................................
1
6 9181015330203 WARNING LABEL .................................................................................
1
7 414050004 * PIN (5/16
in. x 1-3/4 in.) ........................................................................ 1
8 9181015330202 HAND WARNING LABEL ......................................................................
1
9 0181010801 * SCREW AND WASHER (M4
x 7 mm) .................................................... 2
10 0181010303 ANTI-KICK BACK PAWL .......................................................................
2
11 0181010202 SPACER CAP ........................................................................................
2
12 A131011601 RIVING KNIFE .......................................................................................
1
PARTS LIST FOR FIGURE B
Key Part
No. Number Description Qty.
