RYOBI 10 in. (254 mm) TABLE SAW - MODEL NO. BTS20R
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
TABLE SAW or when ordering repair parts.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
* Standard Hardware Item – May Be Purchased Locally
A131017004 FRONT RAIL ASSEMBLY
(Includes Fig. C Key No. 15, 16, 17;
Fig. D Key No. 6, 7, 8, 9, 10, 20, 21, 22)
1 0131010316-35 THROAT PLATE ...........................................
1
2 410101012 * SCREW (10-24
x 3/4 in. FLAT HD.) .............1
3 0131010502 EXTENSION ROD BUSHING ......................2
4 0131011806 RIGHT OUTFEED BRACKET .......................1
5 410171707 SCREW (10-24 x 5/8 in. TAPPING) ..............4
6 0131010221 RIGHT CARRYING HANDLE .......................1
7 0131010108-94 AUXILIARY HANDLE BRACKET ..................
1
8 0181010227 FENCE LOCKING HANDLE/
AUXILIARY HANDLE .................................1
9 0131010814 * SCREW (M6 x 25 mm HEX HD.) ..................4
10 0131010321 EXTENSION ROD CLAMPING PLATE .........
2
11 0131010225-35 KNOB, EXTENSION ROD ...........................2
PARTS LIST FOR FIGURE C
Key Part
No. Number Description Qty.
Key Part
No. Number Description Qty.
12 0181010317 SPECIAL NUT/RAIL WASHER .....................
2
13 412011065 * WASHER (D8
x D16 x 0.8T) .........................2
14 410011723 * SCREW (5/16-18
x 14 mm HEX HD.) ..........2
15 0131010241 END CAP (LEFT) ..........................................1
16 0131011808 MAIN RAIL ...................................................1
17 9131015330305 SCALE, MAIN RAIL .....................................1
18 0131010229 LEFT CARRYING HANDLE ..........................1
19 410171706
SCREW (10-24 x 1/2 in. TAPPING) ..............6
20 0131011805 LEFT OUTFEED BRACKET .........................
1
21 410331704 * SCREW (1/4-20 x 1/2 in.) ............................4
22 0131010224 BUMPER .....................................................2
23 0131010105-33 TABLE ..........................................................1
24 413011014 C CLIP .........................................................2
25 0131011305 RUBBER PLUG ...........................................2
