RYOBI 10 in. (254 mm) TABLE SAW - MODEL NO. BTS20R
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
TABLE SAW or when ordering repair parts.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
* Standard Hardware Item – May Be Purchased Locally
A131013101 EXTENSION TABLE ASSEMBLY
1 410101012 * SCREW (10-24 FLAT HD.) ..........................
2
2 0131010807 SQUARE BAR .............................................
1
3 9131015335703 TEAR-DOWN LABEL ..................................
1
4 410551701 * SCREW AND WASHER (1/4-20
x 1/2 in.) ... 2
5 9131015335704 SET-UP LABEL ...........................................
1
6 9131015330302 SCALE LABEL, SMALL RAIL ......................
1
7 410132740 * SCREW (8-32
x 21 mm) ............................. 1
8 0131011809 SMALL RAIL ...............................................
1
9 0131010242 END CAP (RIGHT) ......................................
1
10 0131010808 JOINT BAR .................................................
1
11 0181010317 SPECIAL NUT/RAIL WASHER ....................
2
PARTS LIST FOR FIGURE D
Key Part
No. Number Description Qty.
Key Part
No. Number Description Qty.
12 412017086 * WASHER (D11
x D28 x 2.5T) ...................... 2
13 0131010220 MITER GAUGE HOLDER ............................
1
14 412011065 * WASHER (D8
x D16 x 0.8T) ........................ 2
15 410011720 * HEX SCREW (5/16-18
x 3/8 in.) ................. 2
16 0131010806 EXTENSION ROD ......................................
2
17 0131010313 EXTENSION TABLE ...................................
1
18 412021703 LOCK WASHER (
M10) ................................ 2
19 411011712 *
HEX NUT (10-24 UNC) ............................... 2
20 0131011810 SCALE BAR ......................................................
1
21 0133010220 EXTENSION ROD INDICATOR ...................
1
22 410201004 * SCREW (M3
x 6 mm) .................................. 1
23 410182001 * SCREW (4 x 7 mm PAN HD.) .......................2
To Next Page
